Valves for Substrate and Biogas Valves for Substrate and Biogas GEFA Valves for Biogas plants fulfils the users' highest requirements DOMINO gate valves: High security by cutting effect with the closing procedure KG butterfly valves: High life span by solid seat system P R O C E S S T E C H N I K G M B H The maintenance-free COMPACT cross seal (double seal lip profile) guarantees tight shutoff and can be adjusted without interrupting the working process.The self-cleaning effect is achieved by flush-out corners in the body and the cutting edge underneath the gate. Solids and fibres are cut by the cutting edge before tightening is done against the elastic seat. The guidance of the gate is interrupted on stroke length, thus dirt can be ejected.Bidirectional shutoff is achieved by the lateral gate surfaces and the elastic seat which is integrated in the body. The seat is chambered and prestressed mounted. The high finish of the guide- and sealing surface at both sides guarantees long service and tight shutoff. The lateral guidance of the gate prevents the gate from fluttering in either of the flow directions or in throttle positions. Executions Body: Cast iron GG-25, EKB-coated (option GGG 40) Gate: 1.4301 (option 1.4571) Seal: NBR, EPDM, FPM, MVQ, PTFE Mounting parts: steel, EKB-coated or zinc coated Stem / piston: 1.4021 (option: 1.4571) rising or non rising Operation Handwheel Square Gear box Pneumatic cylinder Hydraulic cylinder Electric actuator Special executions Valve with regulation port Full bore Square valve Accessories Mechanical limit switches Proximity switches Solenoid valves Positioners Stem extensions and pillars seat gate surface DOMINO gate valves DOMINO gate valves High security by cutting effect with the closing procedure COMPACT cross seal cutting edge flush-out corners Type KG 2 [ DN 50 – DN 300 ] Wafer type butterfly valve for installation between flanges DIN EN 1092-1, PN 10/16, ANSI 150. Technical Data: Single-piece body, self-centring Face to face dimensions: DIN EN 558-1 series 20 (DIN 3202-K1) Top flange: DIN 3337 - ISO 5211 Test: EN12266-1, P10/P11/P12-A DIN 3230, T3 - BA/BO-1 Control range: 20° - 60° Opening angle Type KG 4 [ DN 50 – DN 300 ] Lug type butterfly valve for installation between flanges DIN EN 1092-1, PN 10/16, ANSI 150. Technical Data: Single-piece body, self-centring Face to face dimensions: DIN EN 558-1 series 20 (DIN 3202-K1) Top flange: DIN 3337 - ISO 5211 Test: EN12266-1, P10/P11/P12-A DIN 3230, T3 - BA/BO-1 Control range: 20° - 60° Opening angle tension tension The solid heavy-walled seat ring assured absolute leak-tightness and a high life span, also with high flow rates. Seat system KG butterfly valves KG butterfly valves High life span by solid seat system Body complete Elastomer-lined with seat ring as multifunctional sealing element Economic initial equipment with single-piece housing construction Centre-mounted process valve for safe and secure industrial usage Advantages edition: 07-2011 Germany Germaniastraße 28 D-44379 DortmundPhone 0049-2 31-610 09-0 Fax 0049-2 31-610 09 80 P.O. Box 70 01 10 D-44371 Dortmundwww.gefa.com gefa@gefa.com Legal structure: Ordinary capital: Executive director: Formation and development: Industrial sectors and products: Employees: Volume: Business premises: Warehouse: Limited company 1.54 million euro Dieter Maier The company was registered in the commercial registry as a limited company on 15.09.1965 Industrial valves - Measurement and control technology - Filter technology 82 employees Approx. 25 million euro The office and operational buildings (Germaniastrasse 28 in Dortmund) is owned by the company, office building / workshop and warehouse 5.450 square metres, company property approx. 13,000 square metres Approx. 5 million euro GEFA Processtechnik GmbH Dortmund is a specialised manufacturing operation in the industrial valve, filtration technology and measurement and control technology sectors. The company was founded in 1964 and was one of the first to carry the three-piece ball valve, soft-seated butterfly valves and pneumatic rack & pinion actuators. In the filtration technology sector, an innovative product line was introduced to the German market by GEFA. The company has been certified since 1992 in accordance with EN ISO 9001 and offers products of the highest reliability and safety. We also have a broad product range available for specific applications. The extensive inventory (5 million euro) guarantees short delivery times.
